Tyco illustra ISE-B04F364-N Standard 4MP IR Mini Bullet IP Camera

Description:



Camera



• Image Sensor : 1 / 2.7” Progressive Scan CMOS
• Effective Pixels : 2560 × 1440
• Min. Illumination : Color: 0.01 Lux @ F1.2, AGC ON; Color: 0.04 Lux @ F2.2, AGC ON; 0 lux with IR
• Shutter Speed : 1 s to 1/100,000 s
• S/N Ratio : ≥52 dB
• Angle Adjustment : Any Angle



Lens



• Focal Length : 2.8 mm @ F2.0, 3.6 mm @ F2.2
• Iris Type : Fixed Iris
• Field of View : 2.8 mm @F2.0, horizontal field of view:110°,Vertical: 77.6°; 3.6 mm @F2.2, horizontal field of view: 89°, Vertical: 58°
• Lens Mount : M12



Video



• Video Compression : H.265 / H.264
• H.264 Compression Standard : Base Line / Main Profile / High Profile
• H.265 Compression Standard : Main Profile @ Leve4.1 High Tier
• Resolution : 4MP(2560×1440), 1080P(1920x1080), 720P(1280x720), D1, CIF, 480 x 240
• Max. Frame Rate : 30fps @ 4MP (2560×1440)
• Video Bit Rate : 64Kbps - 5 Mbps
• Multiple Streaming : Triple streams
• Main Stream : 60Hz: 4MP/3MP/1080P(1-30fps); 50Hz: 4MP/3MP/1080P(1-25fps)
• Sub Stream : 60Hz: 720P(1-15fps)/D1 /CIF (1-30fps); 50Hz: 720P(1-12fps)/D1/CIF (1-25fps)
• Third Stream : 60Hz: D1/CIF/480x240 (1-30fps); 50Hz: D1/CIF/480x240 (1-25fps)
• Smart Codec : ROI, 3 zones
• Quality Control : Five levels under VBR; Freely adjustable under CBR
• Image Setting : time stamp, text overlay, flip & mirror, ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, white balance, video rotation, Scheduled profile settings, AGC



Network



• Network Protocol : TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, UPnP, Unicast, Multicast, ICMP, HTTP, HTTPS, DNS, DDNS, RTP, RTCP, IGMP, 802.1X, QoS, Ipv4, Ipv6
• Cyber Security : HTTPS / IP Filter / IEEE 802.1X / Blacklist & whitelist / account security / telnet access control / serial password
• Online Connection : Support simultaneous monitoring for up to 4 users; Support multi-stream real time transmission
• Remote Monitoring : Webviewer browsing, Holis Pro, Holis Lite, ExacqVision, Victor
• API : ONVIF Profile (S & G), HAPI3





Interface



• Network : 1 RJ45 10M/100M self-adaptive Ethernet port
• Onboard Storage : Built-in micro SD/SDHC/SDXC slot
• Hardware Reset : Yes





General



• Power Supply : DC12V / PoE
• Power Consumption : < 6W
• Dimensions (mm) : ø 116.7 × 90
• Material : Metals
• Weight : ≈ 0.61kg
• Installation : Ceiling mounting ( Wall mounting available with the junction box and bracket )
• Certification : CE, FCC, UL, BIS
• NDAA Compliant : Yes
• Warranty : 3 years
